Based on the germanium fuzzrite from the 60s
With the 3-way toggle switch pointing to the left, it effectively functions as a homage to the 60s fuzzrite. The purpose of the switch is to adjust the impedance of the clipping stage, resulting in a fuller overall tone. In my opinion, this setup produces a superior and more aggressive blend between the two stages. The middle position of the switch offers a particularly rude sound with more low end.
Notable features include a very low noise and hiss figure, coupled with a high output volume. The pedal utilizes 2x NOS Sanyo 2SB185 high gain germanium transistors, which have been measured, matched, and tested for noise. Additionally, it is designed to be daisy-chained with standard Boss-type pedals. (9vdc negative-centre)
The knob layout features “DEPTH” to the left and “VOLUME” to the right, providing straightforward control over the pedal’s sound characteristics. Also a PRE-GAIN knob (small knob), works as your guitars volume control. Clean up is very good with shimmering highs.
Sized at 120x94x38 mm
New Square wave BD light green hammertone powder finish with brushed raw backplate
Free worldwide 1st class shipping. All prices exclude VAT; EU buyers will see VAT applied at checkout.
Based on the germanium fuzzrite from the 60s
With the 3-way toggle switch pointing to the left, it effectively functions as a homage to the 60s fuzzrite. The purpose of the switch is to adjust the impedance of the clipping stage, resulting in a fuller overall tone. In my opinion, this setup produces a superior and more aggressive blend between the two stages. The middle position of the switch offers a particularly rude sound with more low end.
Notable features include a very low noise and hiss figure, coupled with a high output volume. The pedal utilizes 2x NOS Sanyo 2SB185 high gain germanium transistors, which have been measured, matched, and tested for noise. Additionally, it is designed to be daisy-chained with standard Boss-type pedals. (9vdc negative-centre)
The knob layout features “DEPTH” to the left and “VOLUME” to the right, providing straightforward control over the pedal’s sound characteristics. Also a PRE-GAIN knob (small knob), works as your guitars volume control. Clean up is very good with shimmering highs.
Sized at 120x94x38 mm
New Square wave BD light green hammertone powder finish with brushed raw backplate
Free worldwide 1st class shipping. All prices exclude VAT; EU buyers will see VAT applied at checkout.
